Food

Reliable and Safe Drive Solutions for the Food Industry

NORD DRIVESYSTEMS covers a wide range of food industry applications with industry-specific and innovative drive solutions.

We are familiar with your business and your requirements. We prefer long-term collaboration with our customers and partners. You can rely on us! Together with you we will do everything we can to further strengthen your brand’s reputation.

NORD DRIVESYSTEMS Provides

Extensive application knowledge and technical support
Complete drive solutions from a single source
Strong global presence and service
Thousands of installed drives in the food and beverage industry
Wide range of products with high quality standards
Great reliability, economy and service life
Recognized production quality compliant with international standards

Reliability in the Food Industry

DuoDrive

Integrated gear unit and motor

Power range: 0.35–3.0 kW
Extremely high system efficiency
Compact installation space for flexible use
Wash-down design with NXD tupH surface treatment for the highest hygiene standards
System solution for simple commissioning and plug-and-play

IE5+ synchronous motors (TENV)

Hygienic. Efficient. Compact

Efficiency class: IE5+
Optionally available with IP69K and NXD tupH surface treatment
Worldwide approvals and acceptance
Compact, hygienic design
Constant torque and efficiency over a wide speed range

NORDAC ON/ON+/ON PURE – SK 300P – Variable frequency drive

Strong focus, optimum function

Power range: 0.5 - 4 hp (0.37 - 3 kW)
Protection class: IP55, IP66, IP69 (in preparation)
Wall or motor mounting
Multi-protocol Ethernet interface
Plug-and-play solution for fast commissioning

NORDBLOC.1® Helical Bevel Gear Motor

Performance and design

Power range: 0.16 HP – 12.3 HP
Torque: 443 lb-in – 5841 lb-in
Optional IP69K or NXD tupH surface treatment for maximum protection

UNIVERSAL SMI Worm Gear unit

Quiet and smooth

Power range: 0.16 HP – 5.4 HP
Torque: 186 lb-in – 3780 lb-in
Hygienic wash-down design, optionally with NXD tupH surface treatment

NORDBLOC.1® Helical Inline Gear Motor

The innovative performer

Power range: 0.16 HP – 50 HP
Torque: 266 lb-in – 29,207 lb-in
Hygienic wash-down design, optionally with NXD tupH surface treatment

UNICASE™ Helical Bevel Gear Motor

Powerful and proven

Power range: 0.16 HP - 268 HP
Torque: 1593 lb-in – 442,537 lb-in

UNICASE™ Parallel Shaft Gear Motor

Slim and powerful

Power range: 0.16 HP – 268 HP
Torque: 973 lb-in – 885,075 lb-in
Optional IP69K or NXD tupH surface treatment for maximum protection

MAXXDRIVE® XC Parallel Gear Units

Industrial gear units

2- and 3-stage
High strength precision-made one-piece housing
Modular and flexible design for optimum adaptation to your application
Low running noise

NORDAC BASE Variable Frequency Drive - SK 180E

Compact drive, most important drive functions

Power range: 0.33 – 3 HP (0.25 – 2.2 kW)
Protection class: IP55, IP66
Wall-mount or motor-mount

NORDAC PRO Variable Frequency Drive - SK 500P

Single Product Family with Basic to Advanced Functions

Power range: 0.33 – 30 HP (0.25 – 22 kW)
Protection class: IP20
Multi-protocol Ethernet interface for PROFINET IO, EtherNet/IP, EtherCAT, Ethernet Powerlink, and more
USB interface for voltage-free parameterization, even when the mains power is disconnected.
Multi-encoder interface for multiple axis operation

Arnreiter

Drive Systems Provide Conveying Power in Grain Mill

Explosion-proof NORD drives support the processing of grain and seeds in the mills of Arnreiter Mühle GmbH. They drive conveying and distribution systems reliably and in continuous operation.

Baader Group

Sophisticated Separation Technology

The BAADER Group has been developing separators for the food industry for over 40 years. The product range includes press separators whose tooth chains are driven by robust NORD helical bevel geared motors.

Treif Food Processing

Intelligent Cutting

Treif Maschinenbau GmbH is one of the world's leading manufacturers of equipment and systems for slicing food. An SK 500E AC vector drive featuring a powerful microprocessor and integrated positioning functions allow for swift and precise slicing and dicing. No need for an extra controller!
